Shipping Container House #02 (Gate house) Plans
DESCRIPTION
It's very common for houses to hide the containers used in the construction with coatings, giving the appearance of being a normal house, where we would never imagine that it was made of containers. Not in this house! In this loft the container is the highlight! With two 40ft containers stacked on top of each other, this house has a unique industrial style look.
The container look is perfect for the industrial style, from the concept of the style to the way the containers are manufactured, they are industrialized processes, sheets bent by machines and assembled to be used for transportation. In this house we use this concept and we value this rustic concept.
In the containers we kept the typical container colors, blue and red to transmit the whole life history of the containers and all the new annexes we used the gray and black to bring contrast over all this journey of the containers and to show that there is also room for new possibilities.
We created an external skeleton structure to receive a roof addition. This roof is separated in 3 parts, a slatted one that helps to reduce the solar incidence, but doesn't hinder the air passage and facilitates the access for air conditioner repairs, for example. A glass roof that gives amplitude and a view of the sky in the main bedroom, and a closed part with metal tiles where we can use it as a place for the water tank or a deposit for the batteries of the solar panels. The glass roof with the closed part was also thought to capture rainwater and store it in a space on the first floor.
But the highlight of this house is certainly the large sliding gate that transforms the house from a large metal box to a house full of light and life.
The external structure is very important for the support and balance of this gate that goes out from the edge of the house and unites the external with the internal. Inside we have a loft with a bedroom overlooking the sky.
One of the most important points in this house is the double height, as we used only two 40ft containers, the double height combined with the sliding doors and windows not only helps the temperature of the house, but also amplifies the environment giving the impression that the house is much bigger.
The house uses some concepts of industrial style, such as graffiti, metal coatings, among others. But do not take this as something permanent, if we replace the metal coatings, for other smooth, paint all containers and extensions of a single color, we have the possibility to work with several different styles. Use this design as a base, create and adapt it to your tastes and needs. Welcome to Gate House.
*To see other rooms configurations and modifications options for the house, check the design options booklet.
BASIC FEATURES
Integrated spaces.
1 Bedroom (loft) or 2 Bedrooms (on the design guide booklet)
2 Bathroom
Garage for 1 Car
- Dimension
MINIMUM LOT SIZE: 6x20M / 19,68ft x 65,61ft
- This house uses 2 40FT SHIPPING CONTAINERS
The dimensions of a 40-foot container are:
Dimensions (feet): 40’ long x 8’ wide x 8’ 6” high
Dimensions (meters): 12.19m long x 2.44m wide x 2.59m high
- Areas:
First floor: 32,52m² / 350,04ft²
Second Floor: 16,73m² / 180,08ft²
Total: 49,25m² / 530,12sqft
Projected area (area the house occupies on the lot): 40,28m² / 433,57sqft
Permeability area: 10,52m² / 113,23sqft
- Structure
Container house #02 uses 2 containers as a base, but due to the large cuts in the containers it is advisable to reinforce the structure of the containers.
In this design we also created an external structure for a new roof and a closed balcony and also to support the sliding gate of the house's side façade.
- House Position
Container House #02 (Gate House) was all planned to create spaces with plenty of natural light and ventilation. We used 2 strategies to achieve this:
✔ Protected windows: All the large windows are protected. The large window in the living room has a double height ceiling with 2 layers of thermal protection, one being the gate where it protects from the sun. And the other being the glass doors, where in the cold we can keep the gate open only with the glass doors closed to increase the temperature in the room.
✔ Second layer of roof: We created an external structure to hold a new roof where it provides more protection from the sun and more natural lighting with the glass roof part.
This guide is also in the design guide booklet.
WHAT'S INCLUDED IN THIS PLAN SET
Design Language: English
Available in Meters and Feet/inches
The design is on standard size boards (A1 / Arch D)
All plans are drawn in scale and include:
- Layout Plan: Floor plan that shows the best position for furniture in the room.
- Exterior Elevations: A blueprint picture of all tree sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans for each level showing room dimensions, wall partitions, windows, etc.
- Roof Plan: Floor plan of the roof with dimensions, slopes, materials used, etc.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Detail views: 3d, floor plans and views of project elements such as: doors, stairsways, roof detail, etc. With dimensions and material specifications of the project elements.
- 3D sections: 3d cuts to aid in the understanding of the project.
- Charts for windows and doors.: Chart with specification of all windows and door, dimensions, heights, sill heights. definitions of openings and materials.
- Project Guide: 15-page booklet showing changes you can make to the project, such as: more windows, what materials to use, alternative layouts and position of the house on the lot.
WHAT'S NOT INCLUDED IN THIS PLAN SET
- Structural Plans
- Plumbing Plans
- Electrical Plans
- Heating or air conditioning drawings.
For these projects we advise you to hire a local engineer or company to do these plans and to supervise the construction.
CHOOSE A PACKAGE:
- ESSENTIAL
✓ Architectural plans (PDF format)
✓ Design Guide (PDF format)
✓ Alternative Layout plans
✓ Extended Support (2Months)
- PRIME
✓ Architectural plans (PDF format)
✓ Design Guide (PDF format)
✓ Alternative Layout plans
✓ Editable files (CAD FILES - DWG)
✓ IFC Files ( Construction information in digital format.)
✓ Extended Support (2Months)
✓ House Plan Changes**
✓ E-book "Reduce Cost in Contruction" Coming Soon*
-
What is an DWG file?
The DWG format is an editable file used by professionals that can be used with CAD programs.
What is an IFC file?
IFC is a file used in BIM technology (Building Information Modeling) which contains all the information necessary for the development of complementary projects (structural, electrical, etc.).
If you like our work and desire a custom home design for your land, tailored to your desires and preferences, you can request a quote here:
Custom DesignHowever, please note that projects developed from scratch have a higher price than those already completed. On average, for every 100 sqm/1000 sqft, the starting price is $1,000 USD. The price varies for each project. Please fill out the form to receive your quote.
IMPORTANT NOTES
How much will this house cost to build?
House construction costs are dependent on where the house is built, the level of finish (tile, trim, window quality, etc...) and the site.
We advise you to show the video of the project to a local builder. He will be able to provide you with an estimate of the cost to build.
-
How does the extended support work?
Extended support is provided according to the package you choose and begins as soon as your purchase is completed. You can contact us directly or have your builder, contractor, or engineer reach out. Support is offered exclusively via email or Telegram.
-
What is Gumroad?
Gumroad is a website that helps people sell things online, especially digital products. We use Gumroad to handle payments and deliver the house project files.
-
How do I receive the house plans?
Once the purchase is completed, the website will take you to the download area, where you can download all the project documents. The link to the page will also be sent to the email you used for the purchase.
-
How much time do I have to build the house?
There is no time limit for you to build your house. You can buy the project and build it after 2 years, for example.
-
Do you make modifications to the projects?
Yes, but only for customers who purchase the PRIME package. After the purchase, a form will be sent to you to describe the modifications you want for your house. After reviewing it, we will send you a quote based on the quantity and complexity of the changes you desire. We do not alter the house tour video or the 3D images. The changes will be made only to the architectural plan.
-
How do I handle the supplementary projects (structural, electrical, plumbing, etc)?
For all these supplementary projects, we recommend hiring a local professional to create those supplementary plans tailored to your land's specific requirements and oversee the construction.
-
Are your plans ready to submit to my building department for permitting?
In most places, your local building department may have specific requirements. Some of these requirements, including structural engineering, soils reports and energy efficiency calculations, etc.
The Project was created by an architect but do not have an architectural or engineering signature, and / or stamp-visa. You agree to consult an local /engineer/ builder/ contractor who can advise you and make the necessary changes to bring the house into compliance with the local requirements.
-
What is your return policy?
All sales of our digital products are final, and we do not offer refunds. Due to the nature of digital downloads, we are unable to verify the removal of files from your possession once they have been delivered. When you make a purchase, you are accepting these terms.
We understand that circumstances may vary, and we strive to provide the best customer experience possible. If you encounter any issues with the product or have any questions, please contact our support team, and we will be happy to assist you.
-
Do I own the copyright to the plans?
All plans on this website are protected under the Federal Copyright Act. The copyright owner retains ownership of the original documents. Reproduction, copying, or unauthorized use is strictly prohibited. Purchasing plans grants a limited license to construct a single dwelling. Buying additional sets doesn't permit multiple constructions without permission. To use plans more than once, extended usage requires permission. Copyright violations can lead to substantial penalties.
Additionally, it's important to note that the creation and sale of modified plans based on the original material are also strictly prohibited, and all rights remain with the product's creator. Copyright and licensing for home plans are in place to protect all parties and uphold the intellectual property of the original architect or designer. Copyright laws have been strengthened in recent years, and willful infringement could result in settlements of statutory damages of up to $150.000, along with attorney fees, damages, and loss of profits.
-
